90 Degree MDR 36 Pin Connector with Clip

Starte 90 degree SCSI MDR 36 pin Connector with clip, the Right angle MDR 36 pin connector pin arrangement in two rows, one on top of the other. The top row has 18 pins and the lower row has 18 pins. It is replacement of 3M Mini Delta Ribbon connector, and often used on the cable for connecting...

Send InquiryChat Now
Product Details

Starte 90 degree SCSI MDR 36 pin Connector with clip, the Right angle MDR 36 pin connector pin arrangement in two rows, one on top of the other. The top row has 18 pins and the lower row has 18 pins. It is replacement of 3M Mini Delta Ribbon connector, and often used on the cable for connecting servo driver


Product Parameters of Angled 36 pin mdr connector with latch:

Item

90 degree angled SCSI MDR 36 pin Cable servo Connector with latch clip

Brand

Starte

Product type

SCSI cable and connector

No. Of Contact

36 pin

Contact Type

1.27mm cable receptacles Connector solder type

Options

Male, latch clip, Assembly

Wire

28AWG or 30AWG support

Contact Finishes

Gold Selective Plating

MOQ

1 PCS

Sample

Free

Package

Bags

Warranty

Two years

90 degree angled SCSI MDR 36 pin Cable servo Connector with latch clip.jpg

Technical Parameters of 90 degree CN 36 pin male SCSI connector :

Connector Material

Housing

Plastic Thermoplastic P.B.T UL94V-0, Black

Contacts

Copper Alloy Gold Selective Plated

Front Shell

Steel, Nickel Plated Over Copper

90 degree angled Metal Cover Material

Back shell

Zinc Alloy, Nickel Plated Over Copper

Spring Latch

Stainless Steel

Flat Screws

Steel, Nickel Plated Over Copper

Cable Clipper

Steel, Nickel Plated Over Copper

Electrical Characterisitics

Contact Current Rating

1.0 Amp

Dielectric Withstanding Voltage

500V AC

Insulation Resistance

500MΩ/ Min

Contact Resistance

35mΩ /Max

Operation Temperature

-55°C~+105°C


Application of 270 degree angled 36 pin SCSI connector:

1)Servers machines and Drive enclosures equipments,
2)Mass storage machines,PCs and Macs and more peripherals
3)Replace for Panasonic/MITSUBISHI/Matsushita Yaskawa CN1 Connector SCSI 36P servo driver


FAQ:
Q: If i will need to stay in your place for few days, is that possible to book the hotel for me?
A:It’s always my pleasure, hotel booking service is available.

Q: Do you have stock products to sell?
A: Some items have small quantity in stock.

Q: What kind of material you use?
A: High quality ABS plastic, PVC, PVC+Nylon mesh, Copper (optional)

Q: What is your main market?
A: European, North America, South America and East Asia.

Q:.Which payment ways supported?
A: T/T, Paypal. Western Union, L/C, OA.
