Straight IDC Female HD 68 Pin Connector

Starte Straight IDC Female HD 68 pin Connector with screw bracket for flat cable, this 68 pin scsi-3 ribbon connector pin arrangement in two rows, one on top of the other. The top row has 34 pins and the lower row has 34 pins. It is usually used on the flat wire for internal connecting, such as...

Send InquiryChat Now
Product Details

Starte Straight IDC Female HD 68 pin Connector with screw bracket for flat cable, this 68 pin scsi-3 ribbon connector pin arrangement in two rows, one on top of the other. The top row has 34 pins and the lower row has 34 pins. It is usually used on the flat wire for internal connecting, such as SCSI disk, SCSI hard driver.


Product Parameters of HD 68 female ribbon Connector:

Item

IDC type SCSI HD68 pin female ribbon connector

Brand

Starte

Product type

SCSI cable and connector

No. Of Contact

68 pin

Contact Type

1.27mm cable receptacles Connector idc type

Options

Female, screw, Straight Panel Mount

Wire

28AWG or 30AWG support

Contact Finishes

Gold Selective Plating

MOQ

1 PCS

Sample

Free

Package

Bags

Warranty

Two years

HD68 Pin idc female connector with screw bracket for flat cable.jpg

Technical Parameters of SCSI-3 female ribbon Connector:

Connector Material

Housing

Plastic Thermoplastic P.B.T UL94V-0, Black

Contacts

Copper Alloy Gold Selective Plated

Cover

Plastic Thermoplastic P.B.T UL94V-0, Black

Bracket

Ziny Alloy, Nickle Plated Over Copper

Electrical Characterisitics

Contact Current Rating

1.0 Amp

Dielectric Withstanding Voltage

500V AC

Insulation Resistance

500MΩ/ Min

Contact Resistance

35mΩ /Max

Operation Temperature

-55°C~+105°C


Application of HD68 Pin idc female connector with screw bracket:
1)motion controller, PCIx card
2)Servers machines and Drive enclosures equipments,
3)RAIDs,CD ROM,File Server


FAQ:
Q: Can I vist your company?
A:All our clients, from home or abroad, are warmly welcome to visit us!


Q: Are you trading company or manufacturer?
A: We are trading company with long term cooperation factories.


Q: What kind of material you use?
A: High quality ABS plastic, PVC, PVC+Nylon mesh, Copper (optional)


Q: Which country is your largest market?
A: France is largest.


Q: What is your trade term supported?
A: EXW, FOB, CIF, CFR, DDU are all available.
