DB78 78 Pin Male To Female Cable

This DB78 78 pin Male to Female Cable is used to extend equipment which utilizes 78-pin DSUB connectors, such as 78-pin DSUB breakout boards or PCI card with 78 pin connector.

Send InquiryChat Now
Product Details

Starte DB78 78 pin Male to Female Cable, this DB78 Pin to DB78Pin Male to female Cable ends come with jack sockets screwed onto the thumbscrews (see photos). These jack sockets allow a secure connection to a male cable end, as the thumbscrews on the male connector can thread into the jack sockets on the female end.



Product Parameters of SUB-D 78-pin male to female Cable:

Item

DB78 78 pin Male to Female Cable

Brand

Starte

Model No.

DSCA043

Cable Type

DB 78 pin Cable

Connector 1

DB78 pin male connector x1

Connector 2

DB78 pin female connector x1

Connector plating

Nickle Plated

Gender

Male to male

Wire

UL 28AWG

Conductor

BC

Pin layout

Straight connection

Jacket

PVC

Shielding

Al-foil and Braid

Sample

Allowed

MOQ

500 pcs

Package

PE bags

Warranty

Two years

OEM

Support



Feature of 78 pin D'Sub M F Twisted Pair Shielded Cable:

1)78-pin Sub-D male connector to Sub-D female connector Cable Assembly

2)Molded cable with strain reliefs

3)Shielded, with drain wire

4)Perfect for RS232 serial data, prototype, control and low-voltage applications using the 78-pin HD78 interface.



Application of 78 Pin D-sub Female to Male Cable:

This DB78 78 pin Male to Female Cable is used to extend equipment which utilizes 78-pin DSUB connectors, such as 78-pin DSUB breakout boards or PCI card with 78 pin connector.




Payment:




Shipment:




FAQ:

Q: What is the after-sale service?
A: Two year warranty and professional technology person to solve your matters.



Q: How do you control the quality?

A: Strict quality controlling system and Multiple testing to slow down the detective items.



Q: Could you provide drawing for Confirming?

A: Yes, drawing provide for confirming with each other, signature on drawing would be better.



Q:Can we print our logo on your own products ?

A: Yes, allowed.



Q:Package support OEM?

A:Yes, it’s allowed.
