Straight Panel Mount IDC Female 50 Pin Connector

Starte Straight Panel Mount IDC Female 50 pin Connector, this Straight Panel Mount IDC 50 pin female Connector pin arrangement in two rows, one on top of the other. The top row has 25 pins and the lower row has 25 pins. Often used on the flat wire for internal connecting, such as SCSI disk, SCSI...

Send InquiryChat Now
Product Details

Starte Straight Panel Mount IDC Female 50 pin Connector, this Straight Panel Mount IDC 50 pin female Connector pin arrangement in two rows, one on top of the other. The top row has 25 pins and the lower row has 25 pins. Often used on the flat wire for internal connecting, such as SCSI disk, SCSI hard driver.


Product Parameters of HD 50 female ribbon Connector:

Item

IDC type SCSI HD50 pin female ribbon connector

Brand

Starte

Product type

SCSI cable and connector

No. Of Contact

50 pin

Contact Type

1.27mm cable receptacles Connector idc type

Options

Female, latch bracket, Straight Panel Mount

Wire

28AWG or 30AWG support

Contact Finishes

Gold Selective Plating

MOQ

1 PCS

Sample

Free

Package

Bags

Warranty

Two years


Technical Parameters of SCSI-2 female ribbon Connector:

Connector Material

Housing

Plastic Thermoplastic P.B.T UL94V-0, Black

Contacts

Copper Alloy Gold Selective Plated

Front Shell

Steel, Nickel Plated Over Copper

Cover&Holder

Plastic Thermoplastic P.B.T UL94V-0, Black

Electrical Characterisitics

Contact Current Rating

1.0 Amp

Dielectric Withstanding Voltage

500V AC

Insulation Resistance

500MΩ/ Min

Contact Resistance

35mΩ /Max

Operation Temperature

-55°C~+105°C


Application of Panel mount HD 50 female IDC connector :

1)motion controller, PCIx card
2)Mass storage machines,PCs and Macs and more peripherals
3)Networking Equipments


FAQ:
Q: How long it takes to make sample?
A: Normal item can be finished in 3 days, special item takes more time.


Q: Mass production would be same with sample quality?
A:Yes, mass production would be strictly same with Drawing and Sample confirmed.


Q:Where is your factory located?
A: Located in Shenzhen City, GuangDong Province, China


Q: Why choose us?
A: Professional manufacturer of cable with development, design, production and sales. Good quality with Competitive price, Faster delivery and Satisfied service.


Q:Which level of quality are your products?
A:We have got CE, FCC certificate so far.
