IDC Header DB 50 Female SCSI Connector

Starte IDC header DB 50 female scsi Connector, the scsi 2 female connector pin arrangement in two rows, one on top of the other. The top row has 25 pins and the lower row has 25 pins. Often used on the cable for connecting servo driver, SCSI Hard Driver, SCSI Scanner, SCSI motion Controller,...

Send InquiryChat Now
Product Details

Starte IDC header DB 50 female scsi Connector, the scsi 2 female connector pin arrangement in two rows, one on top of the other. The top row has 25 pins and the lower row has 25 pins. Often used on the cable for connecting servo driver, SCSI Hard Driver, SCSI Scanner, SCSI motion Controller, SCSI breakout Board.


Product Parameters of HD 50 pin female SCSI Connector:

Item

IDC type SCSI HD 50 pin female connector

Brand

Starte

Product type

SCSI cable and connector

No. Of Contact

50 pin

Contact Type

1.27mm cable receptacles Connector idc type

Options

Male, for molding

Wire

28AWG or 30AWG support

Contact Finishes

Gold Selective Plating

MOQ

1 PCS

Sample

Free

Package

Bags

Warranty

Two years

IDC DB 50 pin female connector.jpg

Technical Parameters of HD 50 pin female cable connector:

Connector Material

Housing

Plastic Thermoplastic P.B.T UL94V-0, Black

Contacts

Copper Alloy Gold Selective Plated

Front Shell

Steel, Nickel Plated Over Copper

Cover&Holder

Plastic Thermoplastic P.B.T UL94V-0, Black

Inner Shell

Steel, Nickel Plated Over Copper

Electrical Characterisitics

Contact Current Rating

1.0 Amp

Dielectric Withstanding Voltage

500V AC

Insulation Resistance

500MΩ/ Min

Contact Resistance

35mΩ /Max

Operation Temperature

-55°C~+105°C


Application of  SCSI ii DB 50 pin female connector:

1)motion controller, PCIx card
2)Servers machines and Drive enclosures equipments,
3)Mass storage machines,PCs and Macs and more peripherals


FAQ:
Q:Is your price competitive?
A: Only good quality Products we supply. Surely we will give you best factory price based on superior product and service.


Q: How long is your product warranty?
A: two years.


Q:Can I send defective items to you directly?
A: We can calcuate the fee after discussion.


Q: Do you provide samples?
A: Yes, sample provided when details are confirmed.


Q: How can I get a sample to check your quality?
A: After price confirmation, we can talk about sample.
